Overview
STRUCTURE CHARACTERISTICS
1. Compact structure: adopting straight line design, the pump are with wonderful appearance, excellent stability, convenient installation.
2. Steady operation: advanced designed double suction impeller is adopted to minimize radial force. With excellent hydraulic model, smooth casting inner and surface of impeller the pumps are with gas- resisting and high efficiency.
3. Bearing: SKF or NSK bearing are adopted to keep operating in steady, sound in low, working period in long.
4. Shaft sealing: BURGMANN hard alloy mechanical sealing or packing sealing are adopted to keep 8000 hours operating time well.
5.Installation: No adjustment while installing, you can certain horizontal or vertical installation according to operating conditions in site.
Technical Data
- Outlet dia. Of pump DN 80-600mm
- Capacity Q ≤6910m3 / h.
- Head H ≤200m Operating temperature T ≤105 ° C
- Solid dia. ≤80mg / L
- Allowable operating pressure ≤25bar
- Allowable testing pressure ≤37.5bar
