Overview
SPECIFICATION
Complete grease pump set for installation to use 200-liter grease tank including a stationary tank.
QUALIFICATION
MODEL: 428262 RATIO 55: 1 MASTER 3
- Pressure ratio 55: 1
- Air pressure operating 1.5 - 10 bar (20-140 psi).
- Air consumption 165 l/min at 6 bar
- Maximum output pressure of the liquid 550 bar (7,700 psi).
- Air Motor dimeter 2.75"
- Air Motor Stroke 1.4"
- Maximum free flow delivery 540 g/min at 7 bar, grease no. 2
- Air inlet 1/4" (F).
- Outlet 1/4" (F)
- Sound level 92 dB
STANDARD ACCESSORY
- Grease pump head with pump attachment to 200-kilogram grease cover tank.
- Tank cover
- Follower plate
- Grease gun with Z- Swivel
- Grease hose, size 1/4", length 4 m.
- Filter&Regulator (Option)
Warranty : 1 year warranty
** Product appearance and specifications are subject to change without notice. **
